Cold Air Intake Mod

[Michael Thompson]

I've decided to embark upon yet another modification to my Ouya: A cold air intake modification to the case that will allow cooler outside air to be brought in right over the system's heat sink fan.

First I had to find something to use as a duct.
In this case another piece of industrial scrap in the form of a flanged sleeve bushing made of brass:


Test fits:



The corner post over the fan is going to have to be removed to make room for the duct, so I cut it out at the base with a large pair of cutters and then snipped through the sheet metal holding the post in place.
A little more trimming removed the rest of the plastic from this area:




I then covered the enclosure in masking tape to protect it from getting scratched up while the holes are being made and used a square to establish where the drilling will start.
Note the tiny mark in the tape made by the scribe. That's where the hole will be made:


Close enough for government work!
The round mark you see in the center of the drilled hole is the center of the plastic fan being illuminated by a flashlight.


The stage is now set for punching the larger hole for the duct, which I'll have to do at work.

STAY TUNED FOR PART 2

[rosse119]

Lol this is gonna look insane when done, a right monster.

[Killswitch]

Should put a strobing LED in there
When do we get part 2?

[Michael Thompson]

Should put a strobing LED in there
When do we get part 2?

When it's done, silly.
Replacement LED color is still being decided.

[Hydrus]

Pick a color expecting it to be lighter. I bought a red LED and it looks pink.

[Michael Thompson]

Pick a color expecting it to be lighter. I bought a red LED and it looks pink.

Thanks!
I'll try some different colors I have lying around while I have the cover off.

[Killswitch]

I still say multi color strobe

[derty]

cant wait to see part 2

[Michael Thompson]

PART 2

After taking my Ouya enclosure to work I drilled my pilot hole out and made the first punch.




Now of course...the knockout punch!


CRUNCH


-and the hard part is over!


Test fit


Once I got it all home I set the port with some adhesive and waited...


Internal pic after re-assembly with the port installed



Re-assembled!
I tried to get some shots in better light showing all my mods so far including a view of the fan, but it is difficult without real lighting





So there you go, one cold air intake modification to a stock Ouya enclosure!
With the fan drawing in fresh air from outside the case it effectively pressurizes it and air now exits through the top and bottom vents.

Next: LED!

[Killswitch]

Wait...no LEDs yet? Boooooooo
